Rubber Sleeve Injection Molding Machine

A horizontal injection molding machine is a type of machine used in the manufacturing industry to produce plastic products through the injection molding process. The machine consists of a horizontal barrel, which contains a rotating screw that feeds the plastic pellets into a heated mold. The molten plastic is injected into the mold cavity under high pressure, and after cooling and solidification, the mold is opened, and the finished product is ejected. Horizontal injection molding machines are commonly used for producing plastic parts that have a long flow path or require side gating. They are versatile and can produce a wide range of products, from small parts to larger, more complex components.

Contact Now E-Mail Telephone

Product Details

Rubber sleeve injection molding machine has the following product features:

Compact structure: The horizontal injection molding machine adopts a horizontal layout, which has a compact structure and a small footprint, making it easy to install and layout.
Simple operation: The horizontal injection molding machine adopts a computer control system with a friendly operation interface, simple operation, and easy to master and operate.
Precise injection molding: The horizontal injection molding machine uses precision screws and molds, which can achieve high-precision injection molding through precise control of parameters. The size and quality of the product are stable and reliable.
High production efficiency: The horizontal injection molding machine has fast injection speed and fast cooling time, which can greatly improve production efficiency and shorten the production cycle.
Versatility: Horizontal injection molding machines can adapt to different types and sizes of injection molding, and can produce a variety of plastic products to meet the needs of different customers.
Energy saving and environmental protection: The horizontal injection molding machine adopts advanced energy-saving technology, has low energy consumption and high energy utilization rate, and is environmentally friendly.

Rubber sleeve injection molding machine

To sum up, the horizontal injection molding machine has product features such as compact structure, simple operation, accurate injection molding, high production efficiency, multi-functionality, energy saving and environmental protection. It is widely used in the manufacturing industry and is an efficient and reliable injection molding equipment. .

项目tem 型号Size	LBZ-160B	LBZ-200B	LBZ-300B	LBZ-4008	LBZ-5208	1BZ-650B	LBZ-800B	LBZ-1200B	LBZ-2000B
注射容积（Cm³) Injection volume	1500	2000	3000	4000	10000	20000	28000	28000	56000
锁模力（KN） CI amping force	1600	2000	3000	4000	5200	6500	8000	12000	20000
热板尺寸（mm） Heating plate dim	500x500	550x550	700x600 1300x600	80Ox700 1500x640	900x800 1500x640	1000x900 1600x640	1600x1000	1600x1400 3.500×860	5500x860
开模行程(mm) Mould opening stroke	450	500	600	600	650	650	1000	650	650
最小模厚（mm） Min. mould thickness	60	80	160	160	260	260	610	260	260
装机容量（kw） Total power	23	30	40	40	60	60	100	120	180
机器尺寸（mm）（长×宽×高） Machine dim (LxWxH)	2.8x1.5×2.5	3.5x1.7×2.7	3.7x1.8×3	3.7x1.8x3	5.7×2.5x3.7	5.8x2.5×3.8	7.2×3.5×3.9	7.3x4x3.9	7.1×5.7×3.9
整机重量(Ton) ITotal weight	5.5	6.5	10	10	20	23	40	50	90
