Molding Injection Machine

Injection molding machines come in various sizes and configurations, ranging from small desktop machines to large industrial-scale machines capable of producing complex parts. They are widely used in industries such as automotive, electronics, medical, packaging, and consumer goods manufacturing. Injection molding offers benefits such as high precision, repeatability, and the ability to produce intricate designs with various plastic materials.

Contact Now E-Mail Telephone
Product Details

A molding injection machine, also known as an injection molding machine, is a versatile manufacturing machine used to create a wide range of plastic products. It is one of the most common and widely used methods of plastic part manufacturing, capable of producing complex shapes and high volumes of parts.

Here's how a typical injection molding machine works:

  1. Clamping: The first step is to close the mold using a clamping unit. The mold consists of two halves, the stationary side, and the moving side. The clamping unit applies pressure to keep the mold closed during the injection process.

  2. Injection: Plastic pellets or granules are fed into the injection unit of the machine. The material is heated and melted using a screw and barrel system. Once the plastic material reaches the desired molten state, it is injected into the mold cavity through a nozzle and sprue, filling up the precise shape of the part.

  3. Cooling and Solidification: After the molten plastic is injected into the mold, it cools and solidifies. Cooling channels within the mold assist in this process. The cooling time is a critical parameter that affects the cycle time and quality of the final part.

  4. Mold Opening: Once the plastic has solidified, the clamping unit opens the mold, separating the two halves. The mold may include ejector pins or other mechanisms to help remove the part from the mold.

  5. Ejection: The part is ejected from the mold either automatically or manually, depending on the machine and mold design. Ejector pins or other mechanisms push the part out of the mold.

  6. Repeat Cycle: The machine's automation allows for continuous production, where the mold is closed, plastic material is injected, the part is molded and cooled, the mold opens, and the part is ejected. This cycle is repeated multiple times to produce a large number of parts.

Molding Injection Machine


型号Size
项目ltem

LBP-20L

LBP-200L

LBG-4L

LBG-6L

LBG-10L

LBG-20L

LBG-40L

注射容积(L)
Injection volume

4

6

10

20

40

胶料输出压(Mpa)
Material output
pressure

0-25

0-25

0-25

0-25

0-25

0-25

0-25

胶料输出速度
(L/min)
Average material
output

0-2

0-4

0-6

0-6

0-6

0-6

0-6

简容积(L
The mater ial drum
volume

20

200/20

200/20

200/20

200/20

200/20

200/20

料筒内径(mm
The mater ial drum
diameter

280

571.5/280

571.5/280

571.5/280

571.5/280

571.5/280

571.5/280

装机容量(kw)
Total power

3

3

4.5

4.5

4.5

4.5

4.5

机器尺寸(mm
(长××高)
Machine dim
(LxWxH)

1.1x0.8x1.7

1.6x1.4x1.8

2.2x1x2.3

2.7x1.5x2.3

2.7x1.3x2.7

1.9x1.3x3

3.1x1.5×3.4

机器重量(Ton)
Total weight

1

1.5

2.5

3

3.5

4

5
