Rubber Plate Curing Press
A rubber plate curing press is specific equipment used for curing rubber plates or sheets. It is commonly used in the rubber manufacturing industry for processing various rubber products, such as conveyor belts, gaskets, seals, and flooring.
A rubber plate curing press is specific equipment used for curing rubber plates or sheets. It is commonly used in the rubber manufacturing industry for processing various rubber products, such as conveyor belts, gaskets, seals, and flooring.
The rubber plate curing press typically consists of the following components:
Curing Chamber: This is a reinforced, heat-resistant chamber where the rubber plates are placed for curing. It is designed to withstand the high temperatures and pressures required for the vulcanization process.
Heating System: The curing press is equipped with heating elements, such as electric heaters or steam heating, to heat the curing chamber to the desired temperature. The temperature can be controlled through a thermostat or temperature control system.
Hydraulic or Mechanical Pressure Systems: To apply pressure on the rubber plates during curing, the curing press uses either hydraulic or mechanical systems. Hydraulic presses use hydraulic cylinders and a hydraulic pump to exert pressure, while mechanical presses use mechanical mechanisms like gears or levers.
Control System: The curing press has a control panel with various control instruments and settings for temperature, pressure, curing time, and other variables. This allows operators to set and monitor the curing process parameters.
The curing process involves placing the rubber plates in the curing chamber, heating them to the specified temperature, and applying pressure for a predetermined time. This promotes the cross-linking of rubber molecules, resulting in the desired physical and mechanical properties.
It's important to follow the manufacturer's instructions and guidelines for the operation, maintenance, and safety considerations of the rubber plate curing press. This includes ensuring proper temperature and pressure settings, regular inspection and maintenance of the equipment, and complying with safety protocols to prevent accidents and ensure the production of high-quality cured rubber plates.
型号Size | LBL-50F | LBL-100P | LBL-160P | LBL-200P | LBL-200V | LBL-300V |
锁模力(KN) | 500 | 1000 | 1600 | 2000 | 2000 | 3000 |
热板尺寸(mm) | 400x400 | 450x450 | 500x500 | 550x550 | 500x500 | 600x600 |
开模行程(mm) | 300 | 400 | 450 | 500 | 300 | 250 |
最小模厚(mm) | 60 | 60 | 60 | 60 | 50 | 50 |
装机容量(kw) | 12 | 18 | 20 | 20 | 42 | 51 |
机器尺寸(mm) | 1.4x1x1.7 | 2.1x1.8x2.1 | 2x1.9x 2.4 | 2.2x2x3 | 3.4x2.1x2.5 | 3.4x2.6×2.6 |
机器重量(Ton) | 3 | 4 | 4.5 | 5.5 | 10 | 14 |
