Vacuum Flatbed Vulcanizing Machine
Vacuum Flatbed Vulcanizing Machine is suitable for some products that require high vulcanization quality, such as rubber seals, rubber tubes, etc. It can effectively improve the vulcanization quality and production efficiency of products, and reduce defects such as bubbles and pores that may occur during the vulcanization process.
The vacuum flat vulcanizer is a special vulcanization equipment that combines flat vulcanizer and vacuum technology.
In a traditional flat vulcanizer, pressure is used to heat and vulcanize the rubber product into shape. The vacuum flat vulcanizing machine adds a vacuum system on this basis. By extracting air and reducing environmental pressure, the vulcanization quality and efficiency of rubber products can be improved.
The operating principle of the vacuum plate vulcanizing machine is as follows: First, place the rubber product in the middle of the plate of the vulcanizing machine. Then, start the vacuum pump to extract the air to form a vacuum environment. Next, the temperature of the vulcanizer is heated to bring the rubber product to the temperature required for vulcanization. In a vacuum environment, the vulcanization process of rubber products will be more uniform and thorough.
Vacuum Flatbed Vulcanizing Machine is suitable for some products that require high vulcanization quality, such as rubber seals, rubber tubes, etc. It can effectively improve the vulcanization quality and production efficiency of products, and reduce defects such as bubbles and pores that may occur during the vulcanization process.
Hope this answer helps you! If you have additional questions or need further assistance, please feel free to let me know.
型号Size | LBL-50F | LBL-100P | LBL-160P | LBL-200P | LBL-200V | LBL-300V |
锁模力(KN) | 500 | 1000 | 1600 | 2000 | 2000 | 3000 |
热板尺寸(mm) | 400x400 | 450x450 | 500x500 | 550x550 | 500x500 | 600x600 |
开模行程(mm) | 300 | 400 | 450 | 500 | 300 | 250 |
最小模厚(mm) | 60 | 60 | 60 | 60 | 50 | 50 |
装机容量(kw) | 12 | 18 | 20 | 20 | 42 | 51 |
机器尺寸(mm) | 1.4x1x1.7 | 2.1x1.8x2.1 | 2x1.9x 2.4 | 2.2x2x3 | 3.4x2.1x2.5 | 3.4x2.6×2.6 |
机器重量(Ton) | 3 | 4 | 4.5 | 5.5 | 10 | 14 |
